Compound Module Ieee802154NarrowbandScalarReceiver

Package: inet.physicallayer.ieee802154.packetlevel
File: src/inet/physicallayer/ieee802154/packetlevel/Ieee802154NarrowbandScalarReceiver.ned

(no description)

Usage diagram:

The following diagram shows usage relationships between types. Unresolved types are missing from the diagram.

Inheritance diagram:

The following diagram shows inheritance relationships for this type. Unresolved types are missing from the diagram.

Extends:

Name	Type	Description
NarrowbandReceiverBase	compound module	This module servces as a base module for narrowband receiver models.

Parameters:

Name	Type	Default value	Description
energyDetection	double		no signal is detected at all below this reception power threshold (idle state)
sensitivity	double		reception is not possible if the signal power is below sensitivity (idle or busy states)
snirThreshold	double		reception is not successful if the SNIR is below this threshold (unsuccessful reception)
carrierFrequency	double		center frequency of the band where this receiver listens on the medium
bandwidth	double		bandwidth of the band where this receiver listens on the medium
errorModelType	string	"APSKErrorModel"	NED type of the error model
modulation	string	"DSSS-OQPSK-16"	one of "BPSK", "16-QAM", "256-QAM"
minInterferencePower	double

Properties:

Name	Value	Description
display	i=block/wrx
class	Ieee802154NarrowbandScalarReceiver

Source code:

module Ieee802154NarrowbandScalarReceiver extends NarrowbandReceiverBase
{
    parameters:
        modulation = default("DSSS-OQPSK-16");
        errorModelType = default("APSKErrorModel");
        double minInterferencePower @unit(dBm);
        @class(Ieee802154NarrowbandScalarReceiver);
}
